Place of Origin:
China
Model Number:
320
Displacement (L) | 7.01 |
Number of cylinders (units) | 6 |
Bore x stroke (mm) | 105 x 135 |
The maximum flow of the main pump (l/min) | 429 |
Working hydraulic oil circuit (Mpa) | 35 |
Walking hydraulic circuit (Mpa) | 34.3 |
Rotary hydraulic circuit (Mpa) | 26.8 |
Fuel tank (L) | 345 |
Hydraulic oil tank (L) | 128 |
Hydraulic system (L) | 218 |
Engine oil replacement volume (L) | 15 |
Coolant (L) | 32 |
Total transport length (mm) | 9530 |
Total transport width (mm) | 2980 |
Total transport height (mm) | 2960 |
Total track length (mm) | 4450 |
Track shoe width (mm) | 600 |
Track Gauge (mm) | 2380 |
Minimum ground clearance (mm ) | 470 |
Counterweight ground clearance (mm) | 1050 |
Rear turning radius (mm) | 2830 |
The maximum digging radius of the parking surface (mm) | 9860 |
Maximum digging depth (mm) | 6720 |
Maximum digging height (mm) | 9370 |
Maximum unloading height (mm) | 6490 |
Maximum vertical digging depth (mm) | 5190 |
