Place of Origin:
China
Tonnage (ton) | 36 |
Working weight of the machine (kg) | 36200 |
Bucket capacity (m3) | 2.1 |
Boom length (mm) | 6500 |
Bucket rod length (mm) | 3200 |
Rotary speed (rpm) | 8.75 |
Rotary torque (Nm) | 144 |
Walking speed (km/h) | 4.7 |
Climbing ability (%) | 70 |
Rated power (kw/rpm) | 234/1800 |
Displacement (L) | 9.3 |
Cylinder diameter × stroke (mm) | 115*149 |
Maximum flow of main pump (l/min) | 558 |
Fuel tank (L) | 600 |
Total transport length (mm) | 11170 |
Total transport width (mm) | 3190 |
Total transport height (mm) | 3170 |
Track gauge (mm) | 2590 |
Minimum ground clearance (mm) | 510 |
Counterweight ground clearance (mm) | 1250 |
Center spacing of support wheel (mm) | 4040 |
Back end turning radius (mm) | 3530 |
