Original Engine 10 Ton 25 Ton Truck Mobile Crane Mini Truck Crane Easy Operation

Easy Operation Truck Mobile Crane

10 Ton Truck Mobile Crane

25 Ton Truck Mobile Crane

Place of Origin:

Henan, China

Request A Quote

Original Engine 10 Ton 25 Ton Truck Mobile Crane Mini Truck Crane Easy Operation

Product Details

Showroom Location:

None

Rated Loading Capacity:

25 Ton

Max. Lifting Height:

45m

Max. Lifting Load:

25000kg

Hydraulic Cylinder Brand:

Good Brand

Hydraulic Pump Brand:

Top Brand

Hydraulic Valve Brand:

Famous Brand

Engine Brand:

First Brand

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Core Components:

Engine

Weight (KG):

16000 Kg

Year:

2020

Working Hours:

2001-4000

After Warranty Service:

Video Technical Support

Feature:

Truck Crane

Condition:

Used

Warranty:

1 Years

Marketing Type:

Ordinary Product

Span:

360

Application:

Construction

Type:

Telescopic Truck Mounted Crane

Color:

Yellow

Engine:

Original

Highlight:

Easy Operation Truck Mobile Crane

10 Ton Truck Mobile Crane

25 Ton Truck Mobile Crane

Payment & Shipping Terms

Price

$11,000.00/sets 1-2 sets

16 Ton Lifting Capacity 350hp 8*4 Truck Crane with Electronic Stability Control System

Get Best Price

30T.M Hydraulic Manipulator Lifting Mobile Truck Mounted Crane With 257kw Power Source

Get Best Price

8 Ton Mini Truck Mounted Crane With 4m*4 Boom Arm And Eaton Hydraulic Pump

Get Best Price

Original Engine 10 Ton 25 Ton Truck Mobile Crane Mini Truck Crane Easy Operation

Get Best Price

Contact Now

Product Description

PLEASE NOTE!!! We have various types and brands of cranes,trucks,and all construction machinerys if this product does not meet your needs, please kindly send us an inquiry to tell us your needs, we will send you the appropriate product information and offer as soon as possible! Many thanks!!!

Product Description

Specification

item	value
Showroom Location	None
Rated Loading Capacity	25 ton
Max. Lifting Height	45m
Max. Lifting Load	25000kg
Place of Origin	China
	Henan
Hydraulic Cylinder Brand	good brand
Hydraulic Pump Brand	top brand
Hydraulic Valve Brand	famous brand
Engine Brand	first brand
Machinery Test Report	Provided
Video outgoing-inspection	Provided
Core Components	Engine
Weight (KG)	16000kg
Year	2020
Working hours	2001-4000
After Warranty Service	Video technical support
Feature	truck crane
Condition	Used
Warranty	1 years
Marketing Type	Ordinary Product
Span	360
Application	construction
Type	Telescopic Truck Mounted Crane
Color	Yellow
Engine	original

Products Description

The Zhonglian ZTC250A562-3 series adopts a 41m large cross-section U-shaped main boom design, with a maximum lifting capacity of 6.8 tons for the fully extended arm. Combined with the stronger lifting capacity of 17MM steel wire rope, it can display leading lifting performance in all working conditions. Equipped with a 125 displacement variable displacement pump, integrated hydraulic system, and self compensating variable amplitude balance valve configuration, providing an excellent micro motion experience; The combination of movements is coherent and smooth, making high-altitude lifting operations more precise and efficient.

Specification

Maximum rated gross lifting weight	80000kg
Maximum lifting moment of basic arm	3450kN.m
Maximum lifting moment of the longest main arm	1862kN.m
Maximum lifting height of basic arm	14.2m
Maximum lifting height of main arm	50.9m
Maximum lifting height of auxiliary arm	67.2m
Maximum speed per rope (main winch)	130m/min
Maximum speed of single rope (secondary winch) m/min	130m/min
Boom lifting time	65s
Boom extension time	145s
Rated power	280/1900kW/r/min
Output torque	1800/(1100-1450)
Rotational speed	0~1.6 r/min
Braking distance	≤10m
Maximum travelling speed	89 km/h
Maximum climbing grade	48%
Minimum turning diameter	24m
Angle of approach	18°
Departure Angle	12°
Minimum ground clearance	325mm
Fuel consumption per 100 km	41L
Dead weight in running condition (total mass)	48000kg
Total vehicle quality	47870kg
Front axle load	22000kg
Rear axle load	26000kg
Overall dimensions (length x width x height)	14800x3000x3910mm
Leg longitudinal distance	6.71m
Lateral leg distance	Full extension 8.4m ,Half stretch 5.8m
Tail radius	4310mm
Main arm length	12.7~50.0m
Main arm elevation	-1~80 °
Auxiliary arm length	9.5/16 m
Auxiliary arm mounting Angle	0, 15, 30°
