SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine

Hydraulic Cylinder Crawler Crane

SCC1500A-6 Crawler Crane

150 Ton Crawler Crane

Place of Origin:

Hunan, China

Request A Quote

SCC1500A-6 150 Ton Crawler Crane With Hydraulic Cylinder And Weichai Engine

Product Details

Showroom Location:

China

Rated Loading Capacity:

150 Ton

Max. Lifting Height:

60M, 65m

Max. Lifting Load:

50 Ton

Hydraulic Cylinder Brand:

Other

Hydraulic Pump Brand:

Kawasaki

Hydraulic Valve Brand:

Eaton

Engine Brand:

WEICHAI

Machinery Test Report:

Provided

Video Outgoing-inspection:

Provided

Core Components:

Pressure Vessel, Bearing, Pump, Gearbox, Engine

Weight (KG):

50000 Kg

Year:

2021

Working Hours:

900H

Capacity:

150 Ton

Model:

SCC1500A-6

Crane Type:

Crawler Crane

Engine:

Weichai Engine

Max Lifting Capacity:

150 Ton

Warranty:

6 Month

Applicable Industries:

Construction Engineering

Loading Capacity:

150 Ton

Highlight:

Hydraulic Cylinder Crawler Crane

SCC1500A-6 Crawler Crane

150 Ton Crawler Crane

Payment & Shipping Terms

Price

$102,900.00/units 1-2 units

800 Ton Crawler Crane in Excellent Working Condition for Your Construction Needs

Get Best Price

85 Ton ZCC850 Hydraulic Crawler Crane in Construction Lifting Hoisting Machinery

Get Best Price

Used QUY55 55 Ton Crawler Crane for Construction Gradeability 30% Original Sale

Get Best Price

25 Ton 50 T 55 Ton 75ton Crawler Crane Lifting Machine with Other Hydraulic Pump Top

Get Best Price

Contact Now

Product Description

Products Description

Specification

Item					Unit	Value	Remarks
Max. lifting capacity × radius					t × m	80×4
Max. lifting capacity on fixed jib					t	7
Max. lifting capacity of luffing jib					t	15
Main boom length					m	13 - 58
Fixed jib length					m	6/18
Max. length of main boom with fixed jib					t	49+18
Luffing jib length					m	16m-34m
Max. main boom +max. luffing jib					m	43.5m+34m
Derricking angle					.	30 - 80
Fixed jib angle					.	10, 30
Max. rope speed			Hoisting winch 1	m/min	125/110	With optional free-fall function
of winches			Hoisting winch 2		125
			Derricking winch		93
Slewing speed					rpm	0-2
Traveling speed					km/h	0-1.57
Max. gradeability					%	30	With basic boom and counterweight over front
Ground pressure					Mpa	0.083
Deadweight					t	72.8	With basic boom
Crane counterweight					t	27
Overall dimensions(L × W × H)					m	13500×5000 (3400) ×3200	With A-frame and main boom pivot section
Engine			Model		WP10.270N	Weichai Power
				Rated power / rotational speed	kW/r/min	199/1900
				Max. output torque /rotational speed	Nm/r/min	1270/1200-1500
				Exhaust emission		National StageⅡ
Distance between track center × crawler contact length × crawler width					mm	2600 ×5440×800	Crawler carrier retracted
					mm			4200 ×5440×800	Crawler carrier extended
Noise	Noise level outside operator’s cab during operation			(dB)	≤107
Noise		Noise level in operator’s cab during operation		(dB)		≤79
