Construction Machine Tower Crane 8ton 12ton 25ton With 2500KN Rated Lifting Moment

2500KN Construction Machine Tower Crane

12ton Construction Machine Tower Crane

8ton Construction Machine Tower Crane

Place of Origin:

Henan, China

Brand Name:

Tarzan

Request A Quote

Construction Machine Tower Crane 8ton 12ton 25ton With 2500KN Rated Lifting Moment

Product Details

Feature:

Tower Crane

Applicable Industries:

Construction Works

Showroom Location:

China

Video Outgoing-inspection:

Provided

Machinery Test Report:

Provided

Marketing Type:

New Product 2023

Warranty Of Core Components:

1 Year

Core Components:

PLC, Engine, Bearing, Gearbox, Pressure Vessel, Pump

Condition:

New

Application:

Construction Of High-rise

Rated Loading Capacity:

12ton

Rated Lifting Moment:

2500KN

Max. Lifting Height:

Span:

70m

Warranty:

1 Year

UNIQUE SELLING POINT:

High Operating Efficiency

Weight (KG):

88000 Kg

Max Working Radius (m):

Height (m):

Max Load (T):

Tip Load (T):

2.5

Main Material Specs (mm):

L200X208 Angle Steel Welding

Counter Weight (T):

17.6

Total Weight (T):

Radius-changing Speed (m/min):

0-0.7 Frequency Conversion

Total Motor Power (kw):

Mast Section Dimension (m):

2X2X3

Highlight:

2500KN Construction Machine Tower Crane

12ton Construction Machine Tower Crane

8ton Construction Machine Tower Crane

Payment & Shipping Terms

Price

$36,000.00/units 1-2 units

Zoomlion Tower Crane With 60M Boom 6 Tons Capacity In Vietnam 220m Span

Get Best Price

Energy Mining Syt80 T6012-6 6 Ton 8 Ton Flat-Top Tower Crane With Long Working Radius

Get Best Price

Sany S46 Meters Mixing Integrated Pump Prodmotor 12M Hand Surplus Pump Ton Hoist Crane

Get Best Price

Construction Machine Tower Crane 8ton 12ton 25ton With 2500KN Rated Lifting Moment

Get Best Price

Contact Now

Product Description

Specification

Tower Crane Working Grade			A4
Mechanisms Working Grade			Hoisting			M4
				Slewing			M5
							M4
Rated Hoisting Moment (kN.m)			3110
Max Hoisting Height (m)			Stationary			51.3
Max Hoisting Height (m)				Anchorages			240.3
Working Radius (m)			Min Radius			3.75
Working Radius (m)				Max Radius			75
Max Hoisting Capacity (t)			16
Hoisting Mechanism	Falls	2			4
		Lifting Capacity/ Speed (t/m/min)	4/75	8/37.5	8/37.5	16/18.75
		Power (kW)	60
Trolley Mechanism	Speed (m/min)	0～100
Trolley Mechanism		Power (kW)	11
Slewing Mechanism	Speed（r/min）	0～0.6
Slewing Mechanism		Stall Torque（N.m）	2×145
Climbing Mechanism	Working Pressure (MPa)	31.5
Climbing Mechanism		Speed (m/min)	0.45
Total Power (kW)			86 (excluded Climbing System
Allowable Wind Speed at Top of Crane (m/s)			Climbing					14
				In Service					20
				Out of Service			0～20m	36
								20～100m	42
								100m～	46
Working Temperature (℃)			-20～+40
Power Supply			～380V/50Hz
