CIMC LINYU 6*4 24m3 Aluminum Alloy Tanker Truck for Flammable Liquid Fuel Transport

Flammable Liquid Fuel Tanker Truck

24m3 Aluminum Alloy Tanker Truck

CIMC LINYU Tanker Truck

Place of Origin:

Henan, China

Brand Name:

CIMC LINYU

Request A Quote

Product Details

Condition:

New

Transmission Type:

Manual

Emission Standard:

EURO 5

Fuel Type:

Diesel

Dimensions (L X W X H) (mm):

9800*2500*3500

Gross Vehicle Weight:

9870

After-sales Service Provided:

Video Technical Support, Online Support

Chassis Model:

ZZ1267N464GF1K

Tanker Material:

Aluminum Alloy

Engine Type:

MC07.34-60

Whalebase(mm):

4575+1400

Rated Load(kg):

16000

Gross Weight(kg):

26000

Tank Volume(m3):

Transport Medium:

Petrol

Driving Type:

6*4

Highlight:

Flammable Liquid Fuel Tanker Truck

24m3 Aluminum Alloy Tanker Truck

CIMC LINYU Tanker Truck

Payment & Shipping Terms

Price

$32,040.00/units 1-2 units

CIMC LINYU 6*4 24m3 Aluminum Alloy Tanker Truck for Flammable Liquid Fuel Transport

Get Best Price

CIMC LINYU FAW 8*4 31 Cub Aluminum Alloy Diesel Tanker Truck Petrol Fuel Transport Truck

Get Best Price

CIMC LINYU 8*4 30m3 SINO Aluminum Alloy Diesel Tanker Truck for Liquid Fuel Transport

Get Best Price

CIMC LINYU 8*4 Dongfeng Chassis 20-40m3 Oil Tank Truck With Maximum Torque 1000-1500Nm

Get Best Price

Contact Now

Product Description

Specification

item	value
Condition	New
Transmission Type	Manual
Emission Standard	EURO 5
Fuel Type	Diesel
Dimensions (L x W x H) (mm)	9800×2500×3500
Gross Vehicle Weight	9870
Place of Origin	China
	Henan
Brand Name	CIMC LINYU
After-sales Service Provided	Video technical support, Online support
chassis model	ZZ1267N464GF1K
tanker Material	aluminum alloy
Engine type	MC07.34-60
whalebase(mm)	4575+1400
rated load(kg)	16000
gross weight(kg)	26000
tank volume(m3)	24
Transport medium	petrol
Driving Type	6*4

Product overview

Linyu Series liquid tank is a new high standard light weight tankers made of stainless steel，carbon steel and aluminum alloy.
The tank models include oil tanker, chemical liquid carrier, flammable liquid carrier, food carrier. Referred Europe FFB and the United States the HEIL style, and combined with the domestic market demand, the tank was re-designed based on finite element analysis. The main parts of the tank: shell cover and anti-wave plate adopted better anti-resistance folding dish structure.
Depending on the different stress in different parts of the tank, using different thickness steel, we ensure the lightest under the relevant standards and safety. With unique shape and appearance, Linyu series liquid carrier adopted blast pretreatment process on structure parts. Using special tank tooling fixtures and in conjunction with the automatic protection welder, painting entirely in accordance with the requirements of the luxury passenger bus painting technology standards, the tank body appearance
is beautiful same as bus, and the quality reached industry-leading level. Owned over 20 patents technology, the products conformed to international standards. With the reasonable compatibility, reliable performance, cost-effective, stable quality, the products can meet the differences in demand.

Liquid transport vehicle features

1, light weight: the tank adopts high-end aluminum alloy material, light weight, large volume, high transportation efficiency,
high safety, smooth operation;

2. The new national standard: The use of air suspension to meet the requirements of the national standard, lighter weight, better
efficiency.

3, multi-function: can be independently divided into different media; It can pump in, pump out of the table/but the table,
self-flowing table, but the table and other functions.

4, cost performance: vehicle matching reasonable, stable quality, reliable performance, cost-effective;

5, more professional: tank truck equipped with bottom loading system: oil and gas recovery, anti-overflow system;

6, no pollution: pipe and loading and unloading device using aluminum alloy material, no pollution to the medium.
