Concrete Mixer Truck Electric 8 10 Cbm 8*4 6*4 Chassis

Concrete Mixer Truck Electric 8 10 Cbm 84 64 Chassis

Name: Concrete Mixer Truck Electric 8 10 Cbm 8*4 6*4 Chassis
Brand: Henan Tarzan Heavy Industry Group Co., Ltd.
SKU: CLY5310GJB32FCEV
Price: 45,349.00 USD
Availability: InStock

Electric Concrete Mixer Truck

High Quality Concrete Mixer Truck

8 10 Cbm Concrete Mixer Truck

Place of Origin:

Henan, China

Brand Name:

CIMC LINYU

Model Number:

CLY5310GJB32FCEV

Request A Quote

Product Details

Vehicle Model:

CLY5310GJB32FCEV

Chassis Brand:

YuTong

Chassis Model:

ZKH1311P6FCEVJ

Kerb Weight(KG):

16000

Max. Weight(KG):

31000

Feed Speed(m3/min):

≥3

Discharge Speed(m3/min):

≥2

Discharge Residual Rate(%):

≤0.5

Water Supply System:

Air Pressure Water Supply

Water Tank Volume(L):

450

Vehicle Size(L*W*H) Mm:

10660×2550×3995

Wheelbase(mm):

1950+3500+1350

Motor Model:

TZ400XSYTB97

Peak Power(kw):

380

Power (kWh):

120

Charging Method:

Change Battery

Battery Type:

Lithium Iron Phosphate

Highlight:

Electric Concrete Mixer Truck

High Quality Concrete Mixer Truck

8 10 Cbm Concrete Mixer Truck

Payment & Shipping Terms

Minimum Order Quantity

Price

USD43899-46799/unit

Packaging Details

disassembled for container shipment

Delivery Time

Payment Terms

L/C, T/T

Supply Ability

20000unit/year

Concrete Mixer Truck Electric 8 10 Cbm 84 64 Chassis

Get Best Price

Electric Cement Machine High Mixing Efficiency And Wheelbase Of 2000 3400 1350 Mm

Get Best Price

CIMC LINYU 16cbm Concrete Mixer Truck with Concrete Fast Feed Speed of ≥3 m3/min

Get Best Price

CIMC LINYU 7cbm Diesel Concrete Truck Mixer Machine Advantage High Mixing Efficiency

Get Best Price

Contact Now

Product Description

Product description:CIMC Linyu series concrete mixer trucks cover all products in the mixing industry. The chassis adopts the special chassis of cement concrete ready mixer trucks of major truck brands in the world. Different upper parts manufacturing solutions are customized according to different chassis requirements to achieve the best matching of the whole vehicle and truly achieve the widest range of products. Concrete Mixer Truck Electric 8 10 Cbm 8*4 6*4 Chassis 0

Product Introduction

1.Professional design, Higher quality

The tank body adopts an innovative isometric design, with a lower center of gravity and larger capacity; the material can be selected from low-alloy high-strength structural steel, high-strength steel, and high-performance wear-resistant steel, and the service life is twice that of general manufacturers. Patent number: ZL200820069340.X

2.Special steel, Multi phase stirring

Blades use a "The corrected logarithmic spiral curve" for multi-phase 3D stirring, with fast feed/discharge, good concrete homogeneity, minimal accumulation, and <0.5% residual. Cold-pressed from a special mold, they're made of the same wear-resistant material as the cylinder, ensuring synchronous wear and a lifespan over 150,000m³. Patent number: ZL200820069338.2

3.Multiple configurations, More intelligent

It can be equipped with intelligent systems such as electronically controlled constant speed, intelligent anti-collision, intelligent weighing, remote control, waterway metering, tank mouth sealing, etc., which can reduce the labor intensity of operators and effectively improve the convenience and safety of vehicle use.

4.Humanized design, More safer

①Equipped with a high-power rear work light for safe nighttime construction, ensuring personnel and vehicle safety.

②Anti-slip steps and knurled handrails ensure safe footing and grip. Arc-shaped side guards with rubber sealing strip enhance safety.

③Clear warning signs on the body prevent misoperation

Smart Factory, Ensure Product Quality

1.LASER CUTTING

Laser cutting replaces the original "shearing, cutting, drilling, cutting and grinding" processes to achieve precise cutting;
small error, high precision, energy saving and consumption reduction, environmental protection and no pollution.

2.INTELLIGENT WELDING

Through the automatic feeding system + 3D laser tube cutting machine, a series of production processes such as automatic tube
feeding, cutting, coding, unloading and conveying are realized.

3.AUOMATIC PAINTING

Connect the left and right stations in an orderly series through the suspension conveying method, the automatic heavy conveying system and intelligent central control inter connection system, and realize the automatic and intelligent electrostatic powder spraying on the special vehicle.The production cycle is shortened by 90.6%, organic volatile matter is "zero emission".

4.INTELLIGENT FINALLY ASSEMBLY

This line is divided into three systems: AGV intelligent transfer system, ground drag chain conveying system, plate chain conveying vehicle assembly system. The whole line adopts the single-piece flow pull production mode, which can be combined with the MES system to monitor the operation of the whole line in real time to ensure the continuous and efficient operation of the whole line.

Product Paramenters

Vehicle and chassis parameter	verall dimensions (mm)	10285×2550×3995
	Chassis Brand	Can be customized
	Engine type	Can be customized
	Emission Standards	National Ⅱ Ⅲ Ⅳ Ⅴ
	Curb weight/rated load weight(kg)	14000/16870
	Wheelbase(mm)	1850+3000+1350
	Approach / departure angle(°)	19/18
Mounted concrete mixer parameter	Feed speed(m3/min)	≥3
	Discharge speed(m3/min)	≥2
	Discharge residual rate(%)	≤0.5
	water supply system	Air pressure water supply
	Water tank volume(L)	450
Tips: 1. This parameter only shows one standard model for your reference. 2. Our products are compatible with various truck chassis popular around the world. 3. If you have customization requirements, please do not hesitate to click to contact us. 4. We also provide special complete vehicles and various mounted tank trailer.
