Place of Origin:
China
Brand Name:
AK
ITEMS | CONFIGURATION |
Standard Seating Capacity | 51 seats, adjustable |
Dimensions(mm) | Length -12000, width 2550, height 3720 |
Curb Weight(kg) | 13 500 |
Gross Vehicle Weight(kg) | 18 000 |
Wheelbase | 6 080 |
Max Speed (km/h) | 120 |
Fuel Tank Capacity(L) | 520 |
Engine Model | Weichai, WP 10.375E53, 375 horsepower |
Type, position | Diesel, Rear Engine |
Emission | Euro 5 |
Displacement(L) | 9,72 |
Rated Power(kw/rpm) | 271/1 900 |
Мax Torque(N.m/rpm) | 1 650/1 200 – 1 600 |
Transmission | 6-speed, QIJIANG (analogue ZF) |
Retarder | Electromechanical type, Telma |
Clutch | German brand SACHS, φ430 membrane spring |
Suspension System | Air suspension, 6 air bags |
Front Axle | FANGSHENG, dependent suspension, Disc Brakes |
Rear Axle | FANGSHENG, dependent suspension, Drum Brakes |
