Place of Origin:
China
Brand Name:
JL
use | Passenger coaches, tourist coaches, group coaches |
body length | 11985mm |
body width | 2540,2550mm |
body height | 3970,3860mm |
Vehicle quality | 13710,14490kg |
total mass | 18000kg |
number of seats | 24-55 |
top speed | 100km/h |
engine power | 276,280kW |
Displacement | 10338, 11596mL |
Emission Standards | Euro 5 |
Chassis model | load-bearing body |
front suspension rear suspension | 2645/3340, 2545/3340mm |
number of axes | 2 |
wheelbase | 6000,6100mm |
Axle load | 6500/11500kg |
Front track | 2030, 2080, 2101, 2140, 2050mm |
rear track | 1832,1860,1900mm |
approaching the departure angle | 8/8° |
Number of tires | 6 |
Specification | 295/80R22.5 |
