Place of Origin:
China
Brand Name:
JL
Vehicle parameters/information | ||
use | Passenger coaches, tourist coaches, group coaches | |
body length | 12990mm | |
body width | 2550mm | |
body height | 3695mm | |
Vehicle quality | 14900kg | |
total mass | 21000kg | |
number of seats | 24-56 | |
top speed | 100km/h | |
engine | WP10.375E53 | |
engine power | 276kW | |
Displacement | 9726mL | |
Emission Standards | Euro 5 | |
Chassis model | load-bearing body | |
front suspension rear suspension | 2650/2990mm | |
number of axes | 3 | |
wheelbase | 6000+1350mm | |
Axle load | 5500/10500/5000kg | |
Front track | 2050,2080mm | |
rear track | 1860/2100,1890/2100mm | |
approaching the departure angle | 8/9° | |
Number of tires | 8 | |
Specification | 295/80R22.5 |
