Place of Origin:
Hubei, China
Brand Name:
YT
Dimensions | ||||
Overall Length | 7480 mm | |||
Overall Width | 2430 mm | |||
Overall Height | 3290 mm | |||
Wheel Base | 3800 mm | |||
Front Overhang | 1800 mm | |||
Rear Overhang | 2340mm | |||
Interior Height | 1980 mm | |||
First Step Height | 400 mm | |||
Gross Vehicle Weight | 9400 kg | |||
Seats Capacity | 35 | |||
Luggage Compartment Volume | 2.7 m3 | |||
Engine Model | YC4E150-20 | |||
Engine Type | four cylinders in-line,water-cooled, direct injection | |||
Position/Fuel | Front/disel | |||
Max Torque | 490 | |||
Max Output | 110 kw | |||
Displacement | 4257ml | |||
Emission Standard | Euro II | |||
Chassis Model | EQ6770T3AC | |||
Gear box | Dongfeng five-speed transmision | |||
Front Axle | Hubei gong'an axle(4T) | |||
Rear Axles | Hubei gong'an axle (6T) | |||
Suspension | Multi-spring suspension front 11 rear 13 | |||
Steering | Integral Power steering | |||
Brakes | Dual circuit air brake,drum brake 400*130/155 | rake | ||
Fuel Tank | 135L | |||
Tyres | 8.25-20 | |||
Battery | 6-QA-105 70A | |||
Others | Copper water tank ,exhaust brake,spring actuated | |||
parking brake | ||||
Body Type | Semi-integral body construction | |||
Interior Trimming | Air condition bus's interior, | |||
Double inner luggage rack | ||||
door&door pump | Front set pneumatic outer swinging passenger door | |||
Side Window | Fully:top:fixed,. bottom:push-pull | |||
The color is light green. | ||||
windscreen | Front : laminated glass; Rear : toughened glass | |||
Defroster | Defroster with changeable power 24V,170W | |||
Windscreen Wiper | opposed electric wiper system | |||
Rear reflecting | Rabbit ears rearview mirror,general inner rearview miror | |||
Seats | 2+2,shock-abosorbing driver seat,33+1+1 general seats | |||
Painting | Plain paint |
