Zhengzhou Dongfeng Mid-South Enterprise Co.,Ltd.
E-mail : info@cn-dfm.com.cn
Skype : overseas_dongfeng09
Whatsapp/phone : +8613838205172
Place of Origin:
Hubei, China
Brand Name:
Dongfeng
RHD-Diesel Coach Bus 45+1+1 | ||||||||||||
Overall specification | Model | EQBUS | Engine | Engine model | YCJ245-50 | |||||||
Overall dimension(mm) | 10490 | manufacturer | Yuchai | |||||||||
Overall width(mm) | 2490 | Engine position | Rear | |||||||||
Overall height(mm) | 3565 | Engine Type | 6 cylinders in line, turbo-charger, intercooler | |||||||||
Wheel base(mm) | 5300 | Max power (kw) | 180KW | |||||||||
G.V.W (kg) | 14400 | Fuel tank (L) | 390 | |||||||||
Curb Weight (kg) | 10100 | Dsplacement (L) | 6.49 | |||||||||
Seats capacity (person) | 45+1+1 | Fuel | diesel | |||||||||
Max. speed km/h | ≥100 | Emission standard | Euro 3 | |||||||||
Chassis Data | Items | Standard Equipments | ||||||||||
Clutch | Helical spring Ф420 | |||||||||||
Gear box | FAST 6MT | |||||||||||
Front axle | Dongfeng Dana Axle, disk-type, max 4.7ton | |||||||||||
Rear axle | Dongfeng Dana Axle, drum-type, max 9.7ton | |||||||||||
Suspension | Leaf springs | |||||||||||
Steering | Integral Power steering | |||||||||||
Brake | Air brake, drum type, dual-circuit | |||||||||||
ABS | Chinese ABS with Haldex automatic slack adjuster | |||||||||||
Tyre | 10R22.5 tubeless with one spare tyre | |||||||||||
Others | - | |||||||||||
Bus specification | Driver Position | RHD | ||||||||||
Door & door pump | Out-swing passenger door with remote control | |||||||||||
Side window | Side windows are closed tempered glass | |||||||||||
Heating system | Front defroster,Independent heater | |||||||||||
Rear mirror system | Electric | |||||||||||
A/C system | Equipped 26000Kcal | |||||||||||
Audiovisual system | DVD + 19' Screens, | |||||||||||
Passenger Seat | 45 | |||||||||||
Ventilator | Equipped | |||||||||||
Paint | Normal paint | |||||||||||
Safety belt | All seats with seatblets | |||||||||||
others | Digital clock, tachograph, sun visor for driver, auto fire extinguisher for engine compartment, top hatches with ventilator, GPS |
Send your inquiry directly to us
