Place of Origin:
China
Brand Name:
AK
Vehicle Profile | ||
Dimension (L*W*H) (mm) | 8990×2500×3405 | |
Departure Angle(º) | 8/8 | |
Wheelbase (mm) | 4300 | |
Overhang Front&Rear (mm) | 1900/2790 | |
Seat Capacity | 45+1+1 | |
Curb weight (kg) | 9500 | |
G.V.W (kg) | 13400 | |
Max. Speed (km/h) | 100 | |
Fuel tank volume | 200L | |
Engine Model | YC6J230-20 (Yuchai Engine) | |
Arrangement,Fuel Type | Rear disel engine, vertical, four-stroke,watercooler, turbo charged intercooler | |
Emission Standard | Euro Ⅱ | |
Displacement (L) | 6.5 | |
Rated Power [kw/rpm] | 170/2500 | |
Max. Torque (N.m/rpm) | 810/1400 | |
Gear Box | Manual S6-100, Qijiang brand | |
Front Axle | Fangsheng front axle 4.2T, front disc brake | |
Rear Axle | Fangsheng rear axle 9.5T, rear drum brake | |
ABS | With, Chinese ABS | |
Steering System | Left hand driving, BOSCH power steering | |
Tire | 10R22.5, 7 pcs, stainless wheel cover | |
Air Conditioner | Roof-mounted A/C 22000Kcal/h, BITZER air compressor | |
Defroster | Chinese defroster | |
Luggage Compartment | Manual translational door, double interior overhead luggage racks | |
Passenger Seat | 45 seats ,artificial leather seat covering material ,adjustable, non-movable, with safety belt, in 3+2 layout | |
Rear View Mirror | Electrodynamic type | |
Passenger door | Front passenger door, pneumatic outwards-swung door | |
Front windshield | Front laminated windshield with sun-visor | |
Side window | Side tempered glass,last row 2 pieces windows are sliding, with foldable curtain | |
Safety device | Reflective triangle 1 pcs, parking wedge 2 pcs, reflective vest 1 pcs |
