Brand Name:
Foton
item | value |
Condition | New |
Steering | Left |
Horsepower | 430hp |
Emission Standard | EURO 5 |
Brand Name | Shacman |
Segement | Heavy truck |
Market Segement | Logistics transportation |
Engine Brand | Cummins |
Fuel Type | Diesel |
Engine Capacity | > 8L |
Gear Box Brand | SINOTRUCK |
Transmission Type | Manual |
Forward Shift Number | 12 |
Maximum Torque(Nm) | ≤500Nm |
Gross Vehicle Weight | 15001-20000 kg |
Capacity (Load) | 21 - 30T |
Drive Wheel | 6x4 |
Passengers | 2 |
Seat Rows | Half a row |
Rear Camera | None |
ABS(Antilock Braking System) | Yes |
ESC(Electronic Stability Control System) | None |
Touch Screen | None |
After-sales Service Provided | Video technical support, Overseas Call Centers, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service |
Product name | Tractor Truck Tractor Head |
Driving type | 6*4 Left Hand Driving |
Engine | WP12.430E50 |
Color | Red |
Tractor truck | 371hp 6x4 Tractor Truck |
Gearbox | FAST SF12 |
Cab | X5000 Extended Premium |
Fuel Tank | 400L Aluminum |
Gross vehicle weight | 55 |
Frame | (940-850300(single 8) |
Truck Model | 8x4 | ||||
Truck Brand | SINOTRUCK –HOWO | ||||
Dimension(Lx W xH)（unloaded）（mm） | 10300x2550x3450 mm | ||||
Cargo body size (L*W*H) | 7600 x 2300 x 1500 mm | ||||
Cargo body thickness(mm) | bottom:8mm, side:6mm | ||||
Lift type of Carriage | Central lifting | ||||
Approaching angle/Departure angle（°） | 19/23 | ||||
Overhang(front/rear) (mm) | 1500/1870 | ||||
Wheel base (mm) | 3625+1350 | ||||
Max speed（km/h） | 75 | ||||
Curb weight（kg） | 12600 | ||||
Loading Weight（kg） | 25000 | ||||
Fuel tanker capacity(L) | 300L with locking fuel cap | ||||
Clutch | Single-plate dry clutch Φ430mm | ||||
Engine Model (Steyr technology, made in China) | Model | WD615.47，4- stroke direct injection diesel engine, 6 cylinders in line with water cooling , turbo-charging and inter-cooling | |||
Horse Power | 371HP, 9.726L | ||||
Emission | EURO II | ||||
Fuel Type | Diesel | ||||
Transmission | Model | HW19710,10 forwards and 2 reverse | |||
Brake system | Service brake | Dual circuit compressed air brake | |||
Parking brake | spring energy, compressed air operating on rear wheels | ||||
Auxiliary brake | Engine exhaust brake | ||||
Steering system | Model | hydraulic steering with power assistance Ratio：22.2-26.2 | |||
Front axle | HF9 X2 Loading capacity:9000KG | ||||
Rear axle | HC16 X2, Pressed axle housing, central double reduction with differential locks between axles and wheels Loading capacity: 16000kg | ||||
Color | Optional | ||||
Tire | 12.00R 20.00 10+1 | ||||
Cab | HOWO76 cab | ||||
