Place of Origin:
China
Brand Name:
Toyo ta
specification | overall length(mm) | 7740 | Engine | engine model | EQB140-20 | |||
overall width (mm) | 2160 | engine manufacturer | Cummins | |||||
overall height (mm) | 2660/2720 | engine position/fuel | front-mounted/diesel | |||||
wheel base (mm) | 4435 | engine type | in line, 4 cylinders, | |||||
front/rear track(mm) | 1830/1650 | power rating (kw) | 103 | |||||
approaching and departure angle (º) | 18/17 | max. torque( n.m) | 502 | |||||
first step height (mm) | ≤430 | displacement (ml) | 3.9 | |||||
max. total mass (kg) | 7500 | emission standard | Euro II | |||||
capacity (people/seats) | 30+1 | max. speed (km/h) | 100 | |||||
item | standard specification | selected specification | ||||||
Chassis | transmission | 5+1 Manual gear box | ||||||
clutch | diaphragm type clutch | |||||||
front axle | drum brake | |||||||
rear axle | drum brake | |||||||
suspension | less -leaf spring | |||||||
steering | integral power steering ,left hand driver | |||||||
braking | air controlled dual-circuit brakes; energy storage spring parking brakes | |||||||
oil tank | 85L | |||||||
tire | 215/75R17.5 | |||||||
others | dryer air brake, clutch booster | |||||||
body structure | rectangular hollow section welded | |||||||
