Place of Origin:
China
Item | Unit | Parameter | ||
Dimension of machine | Length (without ladder) | mm | 2477 (2267) | |
Width | mm | 1190 | ||
Height(platform folded) | mm | 2480 (1930) | ||
Wheelbase | mm | 1877 | ||
Wheel track | mm | 1043 | ||
Min. ground clearance (Pit protector ascending/descending) | mm | 100/20 | ||
Dimension of working platform | Length | mm | 2277 | |
Width | mm | 1120 | ||
Height | mm | 1263 | ||
Extension length of the auxiliary platform | mm | 900 | ||
Centroid position of machine | Horizontal distance to front shaft | mm | 950 | |
Height of centroid | mm | 663 | ||
Total mass of machine | kg | 2900 | ||
Max. height of platform | m | 10 | ||
Min. height of platform | m | 1.34 | ||
Max. working height | m | 12 | ||
Min. turning radius (inner wheel/outer wheel) | m | 0/2.3 | ||
Rated load | kg | 320 | ||
Payload of extended platform | kg | 115 | ||
Lifting time | s | 50-75 | ||
Lowering time | s | 43-65 | ||
Drive speed(lowered) | km/h | 3.2 | ||
Drive speed(elevated) | km/h | 0.8 | ||
Max. gradeability | % | 25 | ||
Tilt warning angle (side/forward and backward) | ° | 1.5/3 | ||
Lifting / traveling motor | Model | - | - | |
Rated power | kW | 3.3 | ||
Manufacturer | - | - | ||
Battery | Model | - | T125/3-EV-225 | |
Voltage | v | 24 | ||
Capacity | Ah | 240 | ||
Manufacturer | - | Trojan/Leoch | ||
Tire models | - | Traceless and solid /381×127 | ||
