Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t

Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t

Place of Origin:

China

Contact Us
Request A Quote
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t
Product Details
Feature:
TRUCK CRANE
Application:
Construction
Rated Loading Capacity:
50tons
Max. Lifting Height:
57.7
Warranty:
6 Months
Hydraulic Cylinder Brand:
China
Hydraulic Pump Brand:
China
Hydraulic Valve Brand:
China
Engine Brand:
China
Machinery Test Report:
Provided
Video Outgoing-inspection:
Provided
Warranty Of Core Components:
6 Months
Core Components:
Motor, Pump, Engine
Weight (KG):
41000 Kg
Name:
Truck Crane
Dimension(mm):
13750x2800x3520
Max. Rated Total Lifting Capacity:
50t
Max. Grade Ability:
40%
Total Weight In Travel:
41000kg
Front Axle Load:
15000kg
Rear Axle Load:
26000kg
Max. Travel Speed:
80km/h
Min. Turning Diameter:
24m
Showroom Location:
None
Condition:
Used
Year:
2016, 2016
Marketing Type:
Ordinary Product
Payment & Shipping Terms
Price
$21,826.00/units 1-4 units
Supply Ability
100 Unit/Units per Year
RELATED PRODUCTS
Good price Outdoor Construction Goods Lifting with YUCHAI Engine 80 Ton Telescopic Arm Crane Truck online

Outdoor Construction Goods Lifting with YUCHAI Engine 80 Ton Telescopic Arm Crane Truck

Get Best Price
Good price Mobile Crane Lifting Capacity 80 Tons Telescopic Crane for Used Machinery and Trucks online

Mobile Crane Lifting Capacity 80 Tons Telescopic Crane for Used Machinery and Trucks

Get Best Price
Good price 80 Ton Truck Crane with Telescopic Hydraulic Arm in 2018 and 2001-4000 Working Hours online

80 Ton Truck Crane with Telescopic Hydraulic Arm in 2018 and 2001-4000 Working Hours

Get Best Price
Good price Looking for a Crane Lifting Machine Our 80 Ton Used Mobile Crane Truck Fits the Bill online

Looking for a Crane Lifting Machine Our 80 Ton Used Mobile Crane Truck Fits the Bill

Get Best Price
Contact Us
Contact Now
Product Description
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 0
Product Description
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 1
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 2
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 3
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 4
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 5
Specification
Dimension
Unit
QY50KA
Overall length
mm
13750
Overall width
mm
2800
Overall height
mm
3520
Total weight in travel
kg
41000
Front axle load
kg
15000
Rear axle load
kg
26000
Engine rated power
kW/(r/min)
247/2200
Engine rated torque
N.m/(r/min)
1350/1400
Max. travel speed
km/h
80
Min. turning diameter
m
24
Min. ground clearance
mm
291
Approach angle
°
17
Departure angle
°
11
Max. grade ability
%
40
Fuel consumption for 100km
L
45
Max. rated total lifting capacity
t
50
Min. rated working radius
m
3
Turning radius at turntable tail
m
3.482
Max. lifting torque
kN.m
1764
Base boom
m
11.3
Fully extended boom
m
42.7
Fully extended boom+ jib
m
57.7
Longitudinal outrigger span
m
5.91
Lateral outrigger span
m
6.9
Boom luffing time
s
88
Boom full extension time
s
180
Max. swing speed
r/min
≥2.0
Max. speed of main winch (single rope) (no load)
m/min
≥110
Max. speed of aux. winch (single rope) (no load)
m/min
≥110
Packing & Delivery
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 6
Construction P H Used 50t Truck Crane with Max. Rated Total Lifting Capacity of 50t 7
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
