340Hp Mining Dump Truck with 500-600L Fuel Tank Capacity and 60-70 Ton Loading Capacity

Place of Origin:

SHANGDONG

Brand Name:

LGMG

Request A Quote

Product Details

Condition:

New

Steering:

Left

Horsepower:

451 - 500hp

Emission Standard:

Euro 3

Segement:

Heavy Truck

Market Segement:

Mining Transportation

Engine Brand:

WEICHAI

Fuel Type:

Diesel

Engine Capacity:

> 8L

Cylinders:

Gear Box Brand:

FAST

Transmission Type:

Manual

Forward Shift Number:

Reverse Shift Number:

Maximum Torque(Nm):

≥2500Nm

Dimensions (L X W X H) (mm):

8.45*2.5*3.4

Cargo Tank Dimension:

5.8*2.5*1.7

Cargo Tank Length:

5.3-6.2M

Gross Vehicle Weight:

25-30T

Capacity (Load):

> 50T

Fuel Tank Capacity:

500-600L

Drive Wheel:

6x4

Passengers:

Driver's Seat:

Normal

Rear Camera:

None

Cruise Control:

None

ABS(Antilock Braking System):

None

ESC(Electronic Stability Control System):

None

Touch Screen:

None

Multimedia System:

None

Window:

Manual

Air Conditioner:

Manual

Tire Number:

After-sales Service Provided:

Video Technical Support, Online Support

Model No.:

MT86 MT106

Curb Weight (ton):

Cargo Box Volume (m3):

26 (5.9*3.2*1.5)

Max. Gradbility:

34%

Engine:

WP13G530 530HP

Gearbox:

FAST 8DS240C

Loading Capacity:

60-70 Ton

Tire:

14.00R25

Fuel Tank:

530L

Overall Dimension(LXWXH)(mm):

9070 X 3550 X 3960

Payment & Shipping Terms

Price

$72,160.00/units 1-2 units

Packaging Details

Bulk ship

Supply Ability

100 Unit/Units per Month

None Cruise Control 6X4 Dump Truck for Transportation Engineering Construction

Get Best Price

15500 kg Gross Vehicle Weight SHACMAN 6x4 Dump Truck 350HP 100 Ton 360° Rear Camera

Get Best Price

20 Ton Tipper Truck Good Condition Used 6*4 Dump Truck Self Loading Engine Capacity 8L

Get Best Price

6X4 Dump Truck Automatic Transmission 460 HP Heavy Duty 8 Tyres Deposit Shipment Used

Get Best Price

Contact Now

Product Description

Product Video

Products Description

Efficient, reliable, economic, safe, comfortable, SMART

● Through the perfect combination of wide body car and rigid mine car, a cost-effective mine car designed for carrying large-scale open pit mines with heavy demand and bad working conditions
● The front and rear suspension adopt multi-stage shock absorption, which effectively prolongs the service life of the leaf spring and has strong impact resistance.

● Full hydraulic steering, better comfort than mechanical steering

● Adopt all-wheel dry-type caliper brake, cylinder and exhaust assist brake, improving the safety of the whole machine.

Details Images

Product Paramenters

Model No.			MT60
Curb Weight (ton)			23
Payload (ton)			50
Cargo Box Volume (m3)	Baffled box	26 (5.93.21.5) bottom flange 16mm（NM400）+side flange 10mm (T700)
Max. Gradbility			34%
Max. Speed, km/h	Full loade	44
Max. Speed, km/h		Empty load	44
Axle Payload (KG)	Front Axle	18000
Axle Payload (KG)		Middle and rear Axle	25000+25000
Overall Dimension (mm)			8720×3300×3960
Axle Numbers			3
Tread (mm)	Front	2470
Tread (mm)		Middle+ Rear	2252
Approaching Angle			27°
Departure Angle			43°
Min. Ground Clearance (mm)			362
Wheel Base ( mm)			3625+1450+1450
Engine	Model No.	WEICHAI WD12.420
		Emission	Euro II
		Cylinder Number	6
		Power (HP)	420
		Max. Torque (N.m)	1750
		Rated Rotation speed (r/min)	2200
		Displacement (ml)	11,596
Clutch	Type	single-plate ,dry type，Hydraulic remote control
Clutch		Friction Plate(OD/ID)(mm)	430/242
Gearbox 7DS200	Model No.	FAST 7DS200
Gearbox 7DS200		Gear	7 Forward,1 Reverse
